For your heavy-duty projects, you need more horsepower, 4WD, higher lift capacities, maneuverability in tight spaces, versatility and, of course, comfort. The XR4040 delivers on all fronts with a spacious climate controlled cab, fully synchronized gears and shuttle shift, 4WD, more operating speeds, more front end loader lift capacity, selectable independent or manual PTO, 2 rear remote valves, and extendable lower links. These features help you get real work done and are either unavailable or come as expensive options on competitive models. Don’t settle for less when you can get a fully featured, high performance compact tractor for a lot less.
The XR4040 is powered by an innovative, eco-friendly, TIER 4 engine that delivers powerful , smooth and quiet performance.
The versatile fully synchronized 16 forward and 16 reverse gears allow you to select the operating speed perfectly suited for your operation without the need to stop. Changing direction is simple and easy with the shuttle lever. The loader is quick attach, skid steer compatible and comes with the grill guard. Plus you can carry heavier loads than competitive models with the XR4040’s 2,500 lbs. of loader lift capacity. Easily select between independent or manual PTO with the turn of a switch. Quickly and easily attach hydraulically operated implements like rakes, backhoes, wood splitters and other hydraulically controlled implements with the standard two sets of rear remote valves. And to top it off, the extendable lower links make it a breeze to change 3-point implements. All this makes the XR4040 an ideal combination of power, functionality, and comfort for a lot less than you might expect.
Modern Stylish Design
This compact 4WD is ergonomically designed and stylish with its distinctive blue color.
Shibaura ISM Tier 4 Engine
The Shibaura ISM Tier 4 meets EPA’s most stringent emission standards while delivering rated horsepower quietly with low vibration. Easy Open One-Piece Hood - provides accessibility for easy maintenance.
Large Fuel Tank
The large 10.5 gallon capacity fuel tank provides long operation times.
Synchro Shuttle Transmission
The Synchro Shuttle Transmission makes changing direction easier than competitive non-shuttle gear models. Fully synchronized 12 forward /12 reverse gear transmission provides more operating speeds and easier, smoother shifting than others in its class for superior control, precision and safe operations for virtually any application.
You can select manual or independent PTO and turn on or off with a simple turn of switch.
Select your range with a simple move of the lever.
With Telescopic Lower Links Standard - category 1 with a hitch lift capacity up 1808lbs. This allows for easier attachment of a wide variety of implements. Drawbar Standard – increases the usefulness of the tractor without the additional optional cost. Extendable lower links-makes connecting implements easier.
3-Point Hitch Controls and Fender Mounted Joystick - easily accessible for maximum comfort and convenience. Position and Draft Control - increases ease of use across a wider variety of implements. Easy to reach fender mounted front end loader joystick.
Adjustable Seat with Seat Belt
Deluxe Adjustable Seat with Seat Belt - keeps you in a comfortable even during long operations.
Standard Foldable ROPS
Standard Foldable ROPS (Open Station Models) - allows storage in low clearance buildings or sheds.
Flat Platform – with rubber mat, maximizes space, improves operator comfort, and makes getting on/off tractor easier.
Full Function Dash Panel - important functional data is available at glance for optimum performance and control.
2 Sets of Remotes and Detent Function Standard - adds functionality and improves ease of use by allowing attachment of hydraulically controlled implements without the high, additional costs like others in its class to add the remotes as options.
Choice of Tires
Your Choice of Tires - choose industrial, Ag, or turf tires at no additional cost; subject to dealer inventory.
Front End Loader
Optional Quick Attach(skid-steer) Front End Loader remove or attach in moments. With 2182 lbs. of lift capacity, it outperforms others in its class. Grill guard comes standard with loader rather than an option like others in its class.
Optional Quick Attach Backhoe - remove or attach in seconds. With 89” digging depth, 2,679 lbs. of digging force and 180° swing arc, it outperforms other in its class.
|Gross - Horsepower||40|
|Rated Engine Speed||2600|
|Number of Cylinders||4|
|Transmission Type||Synchro Shuttle|
|Number Of Speeds||16F/16R|
|Max Traveling Speed, mph (km/h)||--|
|Brakes||Wet, Multi Disc|
|Pump Type||Dual Gear Pump|
|Max Total Flow gpm||12.4|
|Category, 3 Point Hitch||1|
|Hitch Lift Capacity, lb||2756|
|No. of standard remote valves||2|
|Type||Independent or Manual|
|Shaft Diameter in. (mm)||1 3/8 (35)|
|Fuel Tank, U.S. gal||10.5|
|Overall Length, in. with 3P||129.4|
|Overall Width (with ag tires), in.||62.4|
|Height to Top of ROPS, in.||96.3|
|Min. Ground Clearance, in||-|
|Total Weight, lb||3,870|
